Chain Bucket Elevators with Central Chain System

Our central chain bucket elevator was developed expressly for maximum conveyor performance; depending on design, sizeable centre distances can thus be achieved, and conveyed volumes can reach 1,900 m³/h depending on bucket width.

Reliable vertical transport of all materials

Their full strength comes to the fore with hot, abrasive or granular bulk material, as in milling operations in the cement industry, for instance. A range of chain types is available to ensure the best possible use. Our central chain bucket elevators are in the field of high permanent temperatures of the material, e.g. for hot clinker.

Our central chain bucket elevators have been developed for conveying maximum capacities of hot material. In order to ensure the safety of the chain different chain sizes are available. Due to special bucket chain, vibrations are not transmitted to the buckets. Conveying heights of up to 70 m are possible. The central chain bucket elevators are also used in the circulation process of grinding plants.

Conveying capacity up to 1,900 m3/h
Centre distances up to 70 m and more

Vertical transport of hot bulk material with grain size up to 100 mm
Different chain sizes with breaking forces up to 2,500 kN available

Beumer Bucket Elevators

Download (PDF, 6 MB)

Download brochure
